The Situation

Our team was asked to reconstruct a bicycle vs. passenger vehicle collision. An SUV was turning right out of a neighborhood onto a two-lane road one morning before sunrise while a cyclist was approaching the intersection from the right. The cyclist had a small headlight, and there was some ambient light from nearby streetlights. We were retained several years after the collision, but there were a few photographs taken after the crash in addition to a police officer’s bodycam video. Our investigation included an inspection of the collision site, the bicycle, and the SUV (which was not damaged in the collision). We also visited the site at night to observe and photograph the lighting conditions.

How We Advised

Our assignment was to assess the speed of the bicycle, reconstruct the collision sequence, and evaluate visibility for the motorist. To determine the speed of the bicycle, we looked at the bicycle gearing and terrain. Combined with published research, we used observations of which gear was engaged to get a range of speeds for the bicyclist. In addition, the cyclist was on a slight downhill stretch after a long uphill stretch. For the speed of the motorist, we relied on his statements combined with generally accepted acceleration rates for right turning vehicles. When we inspected the site and vehicles, we captured 3D laser scans to preserve the geometry. Using photogrammetry to extract 3D information from the provided photographs and bodycam video, we were able to recreate scrape marks on the roadway and the final resting position of the SUV, bicycle, and rider. We then simulated the motion of the vehicle and cyclist throughout the collision and were able to match the physical evidence. From there, we placed a virtual camera in the vehicle to represent the visibility from each person’s position. The vehicle was highly visible from the cyclist position. In one scenario, the bicycle was obscured by the B-pillar of the vehicle throughout his approach. This helped illustrate what may have caused the driver to not see the approaching bicycle on the morning of the collision.
